| 1 |
50252-NF4-750 |
BAND, SUB TANK (se) |
1 |
0.00 |
|
| 2 |
51400-NF4-771 |
FORK ASSY., R FRONT (se) |
1 |
0.00 |
|
| 3 |
51401-NF4-771 |
SPRING, A, FRONT CUSHION (0.6) (se) |
2 |
0.00 |
|
|
51403-NF4-871 |
SPRING, B, FRONT CUSHION (0.65) (se) |
(2) |
0.00 |
|
|
51404-NF4-871 |
SPRING,FR FORK C |
(2) |
46.90 |
|
| 4 |
51402-NF4-771 |
COLLAR, SPRING (se) |
2 |
0.00 |
|
| 5 |
51403-MA0-771 |
SEAT, SPRING |
2 |
2.00 |
|
| 6 |
51410-NF4-771 |
PIPE COMP., FRONT FORK (se) |
2 |
0.00 |
|
| 7 |
51412-422-003 |
RING, BACK UP |
2 |
4.75 |
|
| 8 |
51414-469-003 |
BUSHING, FRONT FORK GUIDE [USE 51414-MBV-711] |
2 |
9.70 |
|
| 9 |
51415-KL4-951 |
BUSH, FRONT FORK SLIDER [USE 51415-MBV-711] |
2 |
8.10 |
|
| 11 |
51412-NF4-771 |
SPRING, REBOUNG (se) |
2 |
0.00 |
|
| 12 |
51450-NF4-771 |
BOLT COMP., FORK (se) |
2 |
0.00 |
|
| 13 |
51421-NF4-771 |
CASE COMP., R BOTTOM (se) |
1 |
0.00 |
|
| 14 |
51432-NF4-771 |
PIECE, OIL LOCK (se) |
2 |
0.00 |
|
| 15 |
51437-NF4-771 |
RING, PISTON (se) |
2 |
0.00 |
|
| 16 |
51440-NF4-771 |
PIPE, SEAT (se) |
2 |
0.00 |
|
| 17 |
51500-NF4-771 |
FORK ASSY., L FRONT (se) |
1 |
0.00 |
|
| 18 |
51521-NF4-771 |
CASE COMP. L BOTTOM (se) |
1 |
0.00 |
|
| 19 |
52400-NF4-771 |
CUSHION ASSY., REAR (se) |
1 |
0.00 |
|
| 20 |
52403-NF4-871 |
SPRING, C, REAR CUSHION (6.0) (se) |
(1) |
0.00 |
|
|
52401-NF4-771 |
SPRING, A, REAR CUSHION (6.4) (se) |
1 |
0.00 |
|
|
52402-NF4-871 |
SPRING, B, REAR CUSHION (6.8) (se) |
(1) |
0.00 |
|
| 21 |
52420-NF4-761 |
JOINT COMP, UPPER (se) |
1 |
0.00 |
|
| 22 |
52424-GC4-831 |
RING, STOPPER |
2 |
2.55 |
|
| 23 |
52452-GC4-831 |
BUSH,DAMPER UPPER |
2 |
13.10 |
|
| 24 |
52459-GC4-003 |
SEAT, REAR SHOCK SPRING (se) |
1 |
0.00 |
|
| 25 |
64105-NF4-000 |
RUBBER, COWLING (se) |
5 |
0.00 |
|
| 26 |
90107-NF4-003 |
BOLT, HEX., 6x8 (se) |
2 |
0.00 |
|
| 27 |
90116-KV3-701 |
BOLT, SOCKET, 8x18 (se) |
2 |
0.00 |
|
| 28 |
96300-08040-00 |
BOLT,FLANGE,DR,8X40 (se) |
2 |
0.00 |
|
| 29 |
90304-GA6-003 |
NUT, AXLE (10mm) |
1 |
2.60 |
|
| 30 |
90306-NF5-003 |
NUT, LOCK (se) |
1 |
0.00 |
|
| 31 |
90543-273-000 |
PACKING, FRONT FORK DRAIN |
2 |
1.70 |
|
| 32 |
90544-283-000 |
WASHER, SPECIAL (8MM) |
2 |
2.05 |
|
| 33 |
51447-KL4-951 |
RING, OIL SEAL STOPPER |
2 |
2.35 |
|
| 34 |
91074-GC4-831 |
BEARING, SPHERICAL, 12 (se) |
1 |
0.00 |
|
| 36 |
91255-MA6-013 |
OIL SEAL (35x48x11) [USE 91255-KBH-003] |
2 |
10.25 |
|
| 37 |
91351-KB7-003 |
DUST SEAL B |
2 |
2.35 |
|
| 38 |
91317-381-771 |
O-RING (27.7x2.4) |
2 |
5.95 |
|
| 39 |
95801-10040-00 |
BOLT, FLANGE (10x40) |
1 |
0.80 |
|
| 40 |
95801-10050-00 |
BOLT, FLANGE (10x50) |
1 |
0.85 |
|
