| 1 |
23210-NF4-760 |
SHAFT COMP,MAIN (se) |
1 |
112.75 |
|
|
23210-NF4-850 |
SHAFT COMP,MAIN (P-2) (se) |
(1) |
0.00 |
|
|
23210-NF4-860 |
SHAFT COMP,MAIN(P-3) (se) |
(1) |
0.00 |
|
|
23210-NF4-880 |
SHAFT COMP,MAIN(P-4) (se) |
(1) |
0.00 |
|
| 2 |
23221-NF4-760 |
SHAFT, COUNTER (se) |
1 |
0.00 |
|
| 3 |
23225-ND4-000 |
COLLAR,COUNTER SHAFT |
1 |
85.20 |
|
| 4 |
23411-NF4-780 |
GEAR,C-LOW (se) |
1 |
0.00 |
|
|
23411-NF4-860 |
GEAR,C-LOW (P-2) (se) |
(1) |
0.00 |
|
|
23411-NF4-870 |
GEAR,C-LOW (P-3) (se) |
(1) |
0.00 |
|
|
23411-NF4-880 |
GEAR,C-LOW(P-4) (se) |
(1) |
0.00 |
|
| 5 |
23412-NF4-750 |
COLLAR,17X20X9 (se) |
1 |
0.00 |
|
| 6 |
23421-NF4-780 |
GEAR, M-2nd (22T) (se) |
1 |
0.00 |
|
|
23421-NF4-870 |
GEAR,M-2 PLAN-2 (se) |
(1) |
0.00 |
|
|
23421-NF4-880 |
GEAR,M-2ND (P-3) (se) |
(1) |
0.00 |
|
| 7 |
23422-GB4-770 |
BUSHING (20x9) |
1 |
9.80 |
|
| 8 |
23431-NF4-780 |
GEAR, C-2nd (33T) (se) |
1 |
0.00 |
|
|
23431-NF4-870 |
GEAR,C-2ND (P-2) (se) |
(1) |
0.00 |
|
|
23431-NF4-880 |
GEAR,C-2ND (P-3) (se) |
(1) |
0.00 |
|
| 9 |
23432-NF4-750 |
COLLAR (22x25x9) |
1 |
8.85 |
|
| 10 |
23441-NF4-780 |
GEAR,M-3RD-4TH (se) |
1 |
0.00 |
|
|
23441-NF4-850 |
GEAR,M-3RD(P-2)-4TH (se) |
(1) |
0.00 |
|
|
23442-NF4-850 |
GEAR, M-3rd(P-3)/4th (22T/26T) (se) |
(1) |
0.00 |
|
|
23443-NF4-850 |
GEAR, M-3rd/4th (P-2) (24T/25T) (se) |
(1) |
0.00 |
|
|
23444-NF4-850 |
GEAR, M-3rd(P-2)/4th (P-2) (21T/25T) (se) |
(1) |
0.00 |
|
|
23445-NF4-850 |
GEAR, M-3rd(P-3)/4th (P-2) (20T/25T) (se) |
(1) |
0.00 |
|
|
23446-NF4-850 |
GEAR,M-3RD-4TH (P-3) (se) |
(1) |
0.00 |
|
|
23447-NF4-850 |
GEAR, M-3rd(P-2)/4th (P-3) (21T/23T) (se) |
(1) |
0.00 |
|
|
23448-NF4-850 |
GEAR, M-3rd(P-3)/4th (P-3) (22T/23T) (se) |
(1) |
0.00 |
|
| 11 |
23451-NF4-780 |
GEAR, C-3rd (31T) (se) |
1 |
0.00 |
|
|
23451-NF4-850 |
GEAR,C-3RD (P-2) (se) |
(1) |
0.00 |
|
|
23451-NF4-860 |
GEAR, C-3rd (P-3) (27T) (se) |
(1) |
0.00 |
|
| 12 |
23456-KA3-000 |
WASHER, LOCK |
1 |
3.85 |
|
| 13 |
23461-NF4-780 |
GEAR,C-4TH (se) |
1 |
0.00 |
|
|
23461-NF4-870 |
GEAR, C-4th (P-2) (30T) (se) |
(1) |
0.00 |
|
|
23461-NF4-880 |
GEAR,C-4TH(P-3) (se) |
(1) |
0.00 |
|
| 14 |
23471-NF4-760 |
GEAR, M-5th (27T) (se) |
1 |
0.00 |
|
|
23471-NF4-850 |
GEAR, M-5th P-3 (24T) (se) |
(1) |
0.00 |
|
|
23471-NF4-860 |
GEAR, M-5th P-2 (26T) (se) |
(1) |
0.00 |
|
| 15 |
23472-ND4-000 |
COLLAR,M-5TH GEAR (se) |
1 |
0.00 |
|
| 16 |
23481-NF4-760 |
GEAR, C-5th (29T) (se) |
1 |
0.00 |
|
|
23481-NF4-850 |
GEAR, C-5th P-3 (25T) (se) |
(1) |
0.00 |
|
|
23481-NF4-860 |
GEAR, C-5th P-2 (29T) (se) |
(1) |
0.00 |
|
| 17 |
23491-NF4-780 |
GEAR M-6TH (se) |
1 |
0.00 |
|
|
23491-NF4-850 |
GEAR,M-6TH (P-3) (se) |
(1) |
0.00 |
|
| 18 |
23501-NF4-780 |
GEAR,C-6TH (se) |
1 |
0.00 |
|
|
23501-NF4-850 |
GEAR,C-6TH (P-3) (se) |
(1) |
0.00 |
|
| 19 |
23802-NF4-650 |
SPROCKET, DRIVE (15T) [USE 23802-NX4-780] |
(1) |
30.20 |
|
|
23803-NF4-650 |
SPROCKET, DRIVE (16T) [USE 23803-NX4-780] |
1 |
30.20 |
|
|
23804-NF4-650 |
SPROCKET,DRIVE (17T) [USE 23804-NX4-780] |
(1) |
30.20 |
|
| 20 |
90446-357-000 |
WASHER, THRUST 17.2mm (T=1.0) |
1 |
4.55 |
|
| 21 |
90452-115-000 |
WASHER 17mm (t 1.0) |
1 |
2.05 |
|
| 22 |
90452-178-000 |
WASHER, THRUST 17mm (T=1.5) |
1 |
2.30 |
|
| 23 |
90461-444-000 |
WASHER, SPLINE 20mm (T=1.5) |
2 |
3.75 |
|
| 24 |
90464-444-000 |
WASHER, SPLINE 22mm (T=1.5) |
4 |
3.75 |
|
| 25 |
90501-KA3-741 |
WASHER, SPRING (8x40) [USE 90501-HB9-003] |
1 |
3.15 |
|
| 26 |
90601-360-000 |
SET RING (20mm T=1.2) |
2 |
4.90 |
|
| 27 |
90602-360-000 |
SET RING 22mm (T=1.2) |
3 |
3.70 |
|
| 28 |
91351-KA3-711 |
D-RING (20mm) |
1 |
3.00 |
|
| 29 |
96300-08020-07 |
BOLT, FLANGE DR (8x20) |
1 |
0.75 |
|
