| 1 |
41201-NX5-790 |
SPROCKET,FINAL DRIVEN 31T (se) |
(1) |
0.00 |
|
|
41202-NX5-790 |
SPROCKET,FINAL DRIVEN 32T (se) |
(1) |
0.00 |
|
|
41203-NX5-000 |
SPROCKET FINAL DRIVEN 33T |
(1) |
154.85 |
|
|
41204-NX5-710 |
SPROCKET,FINAL DRIVEN 34T (se) |
(1) |
0.00 |
|
|
41205-NX5-710 |
SPROCKET,FINAL DRIVEN 35T (se) |
(1) |
0.00 |
|
|
41206-NX5-710 |
SPROCKET,FINAL DRIVEN 36T (se) |
1 |
0.00 |
|
|
41207-NX5-710 |
SPROCKET,FINAL DRIVEN 37T |
(1) |
174.55 |
|
|
41208-NX5-710 |
SPROCKET,FINAL DRIVEN 38T |
(1) |
174.55 |
|
|
41209-NX5-790 |
SPROCKET,FINAL DRIVEN 39T |
(1) |
154.85 |
|
| 2 |
42300-NX5-790 |
AXLE COMP,RR (se) |
1 |
0.00 |
|
| 3 |
42302-MR8-000 |
BOLT, REAR AXLE (se) |
1 |
0.00 |
|
| 4 |
42500-NX5-000 |
BODY ASSY, ECCENTRIC (se) |
1 |
0.00 |
|
| 5 |
42608-NX5-800 |
WHEEL, REAR (MT4.50x18) (se) |
(1) |
0.00 |
|
|
42609-NX5-800 |
WHEEL, REAR (MT4.75x18) (se) |
(1) |
0.00 |
|
|
42601-NX5-800 |
WHEEL, REAR, MT 5.00x17 (se) |
(1) |
0.00 |
|
|
42602-NX5-810 |
WHEEL,REAR(MT5.25X17) (se) |
(1) |
0.00 |
|
|
42603-NX5-700 |
WHEEL,REAR(MT5.50X17) (se) |
1 |
0.00 |
|
| 6 |
42606-MW4-000 |
SPACER, CENTER LOCK |
1 |
35.55 |
|
| 7 |
42620-NX5-000 |
FLANGE COMP, DRIVEN (se) |
1 |
337.80 |
|
| 8 |
42621-MR8-000 |
COLLAR, REAR AXLE DISTANCE |
1 |
8.20 |
|
| 9 |
42720-NC8-000 |
WT,BALANCER 10G |
N |
0.85 |
|
|
42721-NC8-000 |
WEIGHT, BALANCE, 20g (se) |
N |
0.00 |
|
| 10 |
NS-HRC |
NO SALE BY HRC |
1 |
0.00 |
|
| 11 |
42753-ML7-004 |
VALVE, RIM (DUNLOP) |
1 |
7.95 |
|
| 12 |
43110-NX5-000 |
BRACKET, REAR BRAKE [USE 43110-NX5-TS0] |
1 |
222.40 |
|
| 13 |
43121-NX5-000 |
DISK, REAR BRAKE |
1 |
259.20 |
|
| 14 |
90113-MR7-000 |
BOLT, DRIVE PIN |
4 |
2.85 |
|
| 15 |
90114-MW4-850 |
PIN, DRIVE |
4 |
6.20 |
|
| 16 |
90120-NX5-000 |
BOLT, SPROCKET |
6 |
8.45 |
|
| 17 |
90122-NX5-000 |
BOLT, SOCKET (6x15.5) |
4 |
2.85 |
|
| 18 |
90302-NX5-000 |
U-NUT, HEX (6mm) |
4 |
1.30 |
|
| 19 |
90309-428-731 |
NUT, FLANGE LOCK (8mm) |
6 |
3.35 |
|
| 20 |
90315-MR7-000 |
NUT, REAR AXLE (38x1.5) |
1 |
14.80 |
|
| 21 |
90316-NX5-000 |
NUT, REAR AXLE (se) |
1 |
18.30 |
|
| 22 |
90453-752-B00 |
WASHER,6MM |
4 |
1.80 |
|
| 23 |
90501-KV3-951 |
WASHER, CONICAL SPRING (38mm) (se) |
1 |
0.00 |
|
| 24 |
90651-ML0-731 |
CIRCLIP, INTERNAL 62 |
1 |
3.60 |
|
| 25 |
90652-NX5-000 |
CIRCLIP, EXTERNAL (80mm) (se) |
1 |
0.00 |
|
| 26 |
90653-MR7-000 |
SHIM, DRIVEN FLANGE |
1 |
6.90 |
|
| 27 |
90656-MR7-000 |
WASHER, REAR AXLE |
1 |
5.50 |
|
| 28 |
91061-ML0-731 |
BEARING, BALL 6908LU x 2 |
1 |
31.85 |
|
| 29 |
91062-NX5-003 |
BEARING,NEEDLE(RR AXLE) (se) |
1 |
0.00 |
|
| 30 |
94252-16100 |
PIN, LOCK (16mm) |
1 |
0.80 |
|
